GRINDING LODI TC 100.40 CNC
Surface grinding
grinding machines - Used Machines
LODI
07750
07750
Max longitudinal table stroke mm 1200
Min longitudinal table stroke mm 150
Max cross table stroke mm 450
Grinding length mm 1000
Grinding width mm 450
Working table mm 1000x450
Distance between table and spindle axis mm 700
Wheel size mm 400x50x127
Hydraulic group motor HP 4
Spindle motor HP 10
Net weight Kg 5000
Overall dimensions mm 3250x2590x2150
USED MACHINE
