WORK CAPACITY
Maximum grinding length mm 1.200
Max width mm 750
Max height mm 650
WHEELHEAD
Grinding head pover kW 15
Wheel dimensions mm 406 x 152.4 x 100
LONGITUDINAL AXIS TABLE
Wheel speed rpm 1.400
Table speed m/1' 1 - 40
Maximum load table kg 2.500
Ground surface size mm 500 x 2.200
Working stroke mm 2.220
Total stroke mm 2.340
CROSS AXIS HEAD
Fast speed m/1' 5
Jogging adjustable mm 1 - 50
Advances in continuous adjustable mm/1' 0 – 2.000
Min increments of working mm 0,001
Working stroke mm 650
Total stroke mm 685
VERTICAL HEAD
Fast speed m/1' 1,5
Min increments of working mm 0,001
Working stroke mm 690
Total stroke mm 725
DIMENSIONS:
7.050 x 3.485 mm x height 2.680
TOTAL WEIGHT:
kg10.200

USED MACHINE
COD. 211
