CENTERING COMINI MOD. C1T/85
centering machines - Used Machines
VIDEOS:
COMINI
New04148
New04148
AUTOMATIC AND SEMIAUTOMATIC CYCLE
Min e max clamping diameter mm 14-90
Min e max diameter of collar mm 14-65
Max diameter facing and centering mm 85
Min worklenght with 2 vices mm 80
Diameter of inserted tooth cutters mm 140
Cutting speed m/min 140
Speeds of centering spindles rpm 700-2000
Drilling capacity and depth mm 16x22
Total power installed Hp 5
Overall dimensions mm 1400x1100x1300
Total weight approx. Kg 800
USED MACHINE
