- Table surface mm 315x700
- N. slots T 3
- Larghezza dei profilati a T mm 14
- Longitudinal movement of table:
manual control mm 850
hydraulic control mm 750
- Trasversal movement of table:
Manual control mm 360
electro-mechanic control mm 350
- vertical movement head grinding wheel- holder mm 400
- Passata sotto mola nuova mm 350
- Distance internal face of wheel and frame mm 415
- wheel size mm.350x50x127
- Valore della divisione del nonio durante moto trasversale a mano mm 0,010
- Valore delle divisione del nonio durante moto verticale automatico mm 0,002-0,040
- vertical rapid movement m/min 0,15
- transversal rapid rapid m/min 1,6
- tank capacity of hydraulic system liters 100
- tank capacity of coolant equipment liters 100
- net weight of machine Kg. 2900
- gross weight of machine Kg. 3400
- working overall size m 3,18x2,5x2,1
- electric system:
working tension V 380
control tension V 110
- engine spindle tool-holder:
Power Kw 4
turns by min 1500
- engine hydraulic system:
Power Kw 2,2
turns by min 1500
- engine of transv movement:
Power Kw 0,25
turns by min 1000
- Motore of vert. rapid movement:
Power Kw 0,25
turns by min 750
- pump engine coolant equipment:
Power Kw 0,12
turns by min 3000
EQUIPPED WITH:
Magnetic plate mm 600x300

USED MACHINE
