SLOTTING PERINI CMO 250 CNC
slotting - Used Machines
PERINI
06955
06955
Tool stroke adjustable from mm 50 a 250
Distance between column and toolholder mm 450
Distance between table and head mm 460
Distance between rotary table and head mm 410
Vertical movement of slide mm 230
Table dimensions mm 450x940
Rotary table mm 400
Table longitudinal stroke mm 320
Cross stroke mm 300
Head inclination degree 45
Strokes number for minute 17/80
Motor power Hp 3
Approx. overall dimensions mm 2000x1500x1900h
Net weight Kg 1700
USED MACHINE
